Fuses and Protected Circuits

Toyota RAV4 Owner's Manual

See also:

To Deactivate
A soft tap on the brake pedal, pushing the CANCEL button, or normal brake pressure while slowing the vehicle will deactivate Electronic Speed Control without erasing the set speed memory. Pressi ...

Remote starting system
This system uses the Remote Keyless Entry (RKE) transmitter to start the engine conveniently from outside the vehicle while still maintaining security. The system has a range of approximatel ...

Extending and retracting the cargo compartment cover
To extend: pull cargo compartment cover 1 back and clip it into the retainers on the left and right. To retract: unhook cargo compartment cover 1 from the retainers on the left and right ...
