Ford Escape: Replacing front parking lamp/turn signal bulbs - Replacing headlamp bulbs - Bulb Replacement - Lights - Ford Escape Owner's ManualFord Escape: Replacing front parking lamp/turn signal bulbs

1. Make sure the headlamp control is in the off position.
2. Open the hood.
3. Reach over the front bolster.
4. Rotate the bulb socket counterclockwise and remove from the lamp assembly.

5. Carefully pull the bulb out of the

5. Carefully pull the bulb out of the socket and push in the new bulb.
6. Install the bulb socket into the lamp assembly and rotate clockwise.

Replacing front sidemarker bulbs

    Replacing headlamp bulbs
    1. Make sure the headlamp control is in the off position. 2. Open the hood. 3. Reach over the front bolster. 4. Remove the bulb by turning it counterclockwise and then pulling it straight out. ...

    Replacing front sidemarker bulbs
    For bulb replacement, see your authorized dealer. ...
