Dodge Nitro: ENGINE COMPARTMENT — 3.7L - Maintaining your vehicle - Dodge Nitro Owner's ManualDodge Nitro: ENGINE COMPARTMENT — 3.7L

Dodge Nitro / Dodge Nitro Owner's Manual / Maintaining your vehicle / ENGINE COMPARTMENT — 3.7L

1 — Air Cleaner Filter.

1 — Air Cleaner Filter. 6 — Washer Fluid Reservoir. 2 — Engine Oil Dipstick. 7 — Engine Coolant Reservoir. 3 — Brake Fluid Reservoir. 8 — Engine Oil Fill. 4 — Integrated Power Module. 9 — Coolant Pressure Cap. 5 — Battery.

ENGINE COMPARTMENT — 4.0L

1 — Air Cleaner Filter.

1 — Air Cleaner Filter. 6 — Engine Oil Fill. 2 — Engine Oil Dipstick. 7 — Washer Fluid Reservoir. 3 — Brake Fluid Reservoir. 8 — Engine Coolant Reservoir. 4 — Integrated Power Module. 9 — Coolant Pressure Cap. 5 — Battery.
